Battery operated torque wrench
The JUWEL TQS battery torque wrenches have been developed to meet the requirements of our customers and are available with different torque outputs.
With the Juwel battery torque wrenches, you are assured of a robust battery torque wrench
B-TQS Series:
- Robust design
- 1 year warranty, which is expandable
- Available from 100 Nm to 10000 Nm
- Supplied as standard with case, two 6 Ah batteries and fast charger
Options:
- Double safety controls
- Double and sliding reaction arms
| Model | Square drive | Range | RPM | Weight | Dimensions L in mm | Dimensions B in mm |
|---|---|---|---|---|---|---|
| TQS-065 | 3/4″ | 100 – 650 Nm | 70 | 4,75 kg | 380 | 55 |
| TQS-095 | 3/4″ / 1″ | 100 – 950 Nm | 36 | 6,8 kg | 395 | 75 |
| TQS-130 | 1″ | 100 – 1300 Nm | 39 | 7,2 kg | 380 | 75 |
| TQS-220 | 1″ | 100 – 2200 Nm | 18 | 8,2 kg | 420 | 75 |
| TQS-300 | 1″ | 100 – 3000 Nm | 12 | 8,3 kg | 420 | 75 |
| TQS-400 | 1-1/2″ | 150 – 4000 Nm | 11 | 10,5 kg | 435 | 95 |
| TQS-500 | 1-1/2″ | 250 – 5000 Nm | 11 | 12,5 kg | 475 | 95 |
| TQS-600 | 1-1/2″ | 350 – 6000 Nm | 8 | 16 kg | 455 | 115 |
| TQS-700 | 1-1/2″ | 450 – 7000 Nm | 7 | 16 kg | 455 | 115 |
